The ACCU-SCOPE 3000-LED delivers outstanding optical performance, value, and resolution to meet the exacting standards of life science students and instructors.
Compatible products: Excelis HD and Excelis AU-600-HDS
Specifications | |
---|---|
Stand: | Cast alloy aluminum, 16 lbs, (LWH) 387mm x 196mm x 391mm |
Viewing bodies: | Siedentopf binocular or trinocular inclined 30°, rotatable 360°, interpupillary distance 48-75mm |
Eyepieces: | HWF Plan 10x eyepiece, 20mm field of view w built-in diopter adjustment; pointer in one eyepiece; eyepieces are locked in to prevent tampering |
Nosepiece: | Rear facing quadruple, ball bearing nosepiece with click stops to ensure parcentration |
Objectives: | Infinity plan achromatic objectives 4x, 10x, 40x (spring-loaded), 100x oil (spring-loaded) |
Mechanical Stage: | Stage size 140mm x 132mm with X-Y movement range of 76mm x 50mm |
Condenser: | NA 1.25 Abbe condenser (with slot for sliders) on a rack and pinion with iris diaphragm; glass lens in condensing system protects iris diaphragm from tampering |
Focusing: | Coaxial coarse and fine focusing controls |
Illumination: | 3 watt LED with variable intensity control; LED bulb is rated for over 25,000 hours of continued use |
Electrical: | Universal power supply 110v-240v |
Accessories: | Immersion oil, dust cover, and universal power supply 110v-240v |
Warranty: | 5 year mechanical, 5 year electrical, 1 year LED bulb |
Certifications: | ISO 9001, ISO 14001 |
